Highlead GC0318-1

Lockstitch sewing machine with Top & Bottom Feed & Large hook

(Bottom feed & walking foot top feed)

Highlead GC0318-1
The Highlead GC0318-1 is a flat-bed style industrial sewing machine for use on medium & medium-heavy weight materials.

It features a top feed walking foot and bottom feed system, with an alternating foot lift mechanism that is suitable to sew medium & medium-heavy weight materials such as leather, synthetics, canvas, plastics, PVC, webbing, tarpaulin + heavier than normal standard fabrics like upholstery or heavy weight curtains etc.

The balanced sewing machine head benefits from automatic lubrication to reduce wear & tear, resulting in improved durability, lower noise levels, smoother running and minimal maintenance costs.

The fitting of a large hook & base as standard, reduces the number of bobbin changes and helps when using the thicker threads associated with heavier than normal materials. A large stitch length is available up to 8mm.

The heavy duty top walking foot mechanism combined with standard bottom feed; produces a positive feed action and allows true even stitching.

Thick sewing needles are used from size 110 up-to the extra thick size 180.


As well as a standard bottom feed the Highlead GC0318-1 model features a powerful top foot feed assembly

Highlead GC0318 walking foot


Features:
  • Top & bottom feeding
  • Large Hook & base
  • Auto hook lubrication
  • Auto head lubrication
  • Reverse stitch lever
  • Large stitch feature up-to 8mm
Specification:
  • Max sewing speed: 2000rpm
  • Stitch length: 1-8mm
  • Needle bar stroke: 35mm
  • Presser foot lift by hand: 6mm
  • Presser foot lift by knee: 13mm
  • Needle size: DPx17

Highlead GC0318 unit stand

Options:

  • Various sewing feet sets
  • LED needle light kit
  • Energy saving servo motor.
  • Needle position servo motor with speed and acceleration control.




Other walking foot machines:   Highlead GC0618   Highlead GC20618   Highlead GC20688-1D



GC20618-1DZA   GC198-2   GC0388   GC198   HLK-430   GC0618-1-SC   DY-850   GC20618
